A2501(XH-BH) connector 2.5mm pitch

壳体 HOUSING
材料 Material：Nylon 66 UL94V-0

A2501-H Poles Part No. DIM=A DIM=B
2 A2501-H02 2.50 7.30
3 A2501-H03 5.00 9.80
4 A2501-H04 7.50 12.30
7.95
5 A2501-H05 10.00 14.80
6 A2501-H06 12.50 17.30
7 A2501-H07 15.00 19.80 A
B-1.6 4
8 A2501-H08 17.50 22.30
9 A2501-H09 20.00 24.80
10 A2501-H10 22.50 27.30
5.6 11 A2501-H11 25.00 29.80
12 A2501-H12 27.50 32.30
2.5 -- -- -- -- --
A
B 20 A2501-H20 47.50 52.30

针座 WAFER
材料 Material：Nylon 66 UL94V-0 & Brass/Tin-plated A2501(XH-BH) connector 2.5mm [.098] pitch
A2501-DHWV Poles Part No. DIM=A DIM=B
2 A2501-DHWV02 2.50 7.40
5.75 3 A2501-DHWV03 5.00 9.90
-- -- -- -- --
16 A2501-DHWV16 37.50 42.40
2 A2501-DHWVB02 2.50 7.40
14.2 3 A2501-DHWVB03 5.00 9.90
-- -- -- -- --
1.5 16 A2501-DHWVB16 37.50 42.40
3.4 2 A2501-DHWVC02 2.50 7.40
3 A2501-DHWVC03 5.00 9.90
2.5 o 0.64
A 1.6 2 1.45 -- -- -- -- --
B 6.75 16 A2501-DHWVC16 37.50 42.40

材料 Material：Nylon 66 UL94V-0 & Brass/Tin-plated 材料 Material：Nylon 66 UL94V-0 & Brass/Tin-plated
A2501-DHWVB A2501-DHWC

14.2 14.2

1.5
3.4 3.4

2.5 o 0.64 2.5 o 0.64
A 1.6 2 1.45 1.8 A 2 1.45
B 5.75 B 5.75
